PR-7000 CE
Delving into the fascinating world of architecture and design, we encounter a fundamental principle: adaptability. In every construction, aesthetic and functional needs vary, and this is where the PR-7000 CE hinged aluminium door comes into play, a living example of flexibility and versatility in the field of hinged windows. The simplicity of its design is precisely what gives it exceptional value, as it becomes the perfect base for exploring a full range of functionalities and the possibility of fitting into projects of various kinds.
With the Channel 16 and European Groove options, the appearance and functionality of the system can be customised according to the preferences and needs of each project. But that is not all: this system goes further by offering the option of concealed hardware and micro-ventilation, two features that perfectly combine elegance and efficiency.
The PR-7000 CE hinged aluminium door allows a choice between two types of sash, straight or curved, adding an additional dimension to customisation. This choice not only affects the visual appearance, but also the way light is filtered and how interior and exterior spaces interact.
The triple sealing gasket is further proof of the meticulous attention to detail in the design of this system. This feature not only guarantees exceptional acoustic and thermal insulation, but also reinforces the structural integrity of the window in various weather conditions, increasing the building’s efficiency. In a world where every construction is unique, the PR-7000 CE system stands as a reliable element in the creation of spaces that transcend the ordinary.
- Hinged aluminium door available in European Groove and Channel 16
- Option of concealed hardware and micro-ventilation
- Option of straight or curved sash
- Triple sealing gasket
| Air permeability* | UNE-EN 1026:2017; UNE-EN 12207:2017 | Class 4 |
| Water tightness* | UNE-EN 1027:2017; UNE-EN 12208:2000 | Class E900 |
| Wind load resistance* | UNE-EN 12211:2017; UNE-EN 12210:2017 | Class C5 |
| Thermal insulation Uw** | UNE- EN 10077-1:2017 | Up to 2.5 W/m²K |
| Sound insulation Rw | UNE-EN ISO 14351-1:200+A1 Anexo B | 38 dB (-1; -4) |
* Specifications of a 2-sashes window with shutter box of 1230×1480 mm (16 groove)
** Specifications of a 1-sash balcony window of 1100×2200 mm
Maximum recommended dimensions (1 sash): 1400x2300 mm
Maximum recommended weight: 130 kg/sash
Maximum glazing: 36 mm
Polyamide: 40 mm
Hidden hinge and micro-ventilation options
Triple seal
Option of straight or curved sash
Design
The PR-7000 CE system is born under the premise of being one of the hinged window models with the greatest design possibilities. Its simplicity adds value to the high versatility of all its functionalities.
Features
Simple and versatile, this 40 mm deep series has a great capacity to adapt to the aesthetic and functional needs of each construction. In addition, it offers a triple sealing gasket.
Performance
The AEV tests of this system achieve results of air permeability class 4, water tightness class E900, and wind load resistance class C5. The PR-7000 CE window system fits perfectly in warm climatic zones.
Possibilities
The PR-7000 CE door is one of the models offering the greatest constructive possibilities. It allows glazing up to 36 mm and covers the most common opening types, as well as versions for European Groove and Channel 16.
