Glass railing system
Glass Rail PRO is a comprehensive glass railing system that combines safety, aesthetics and multiple solutions
for a quick and precise on-site installation. Its optimised tubular profiles guarantee lightness and strength,
creating an uninterrupted visual connection with the exterior and bringing elegance and high aesthetic value to any space.
Regulatory compliance and simple installation
The transparency of glass and the absence of visual interruptions in a railing provide significant added value to spaces by allowing a total visual connection with the outside. Exlabesa’s new Glass Rail PRO railing has been designed to give full emphasis to glass, without compromising safety. This system has optimised tubular aluminium profiles, which guarantee both lightness and maximum resistance.
Glass Rail PRO offers six installation options, all tested in accordance with CTE and UNE standards, standing out for their versatility and a wide range of solutions and accessories that facilitate assembly and ensure an impeccable finish.
.
Installation options
Installation options adapted to each project
The Glass Rail Pro series has 6 mounting options: U-top mount, L-top mount, U-shaped side mount, inverted U-shaped side mount, Y-shaped side mount and embedded mount. All these options have been tested in accordance with the CTE for private and public use, as well as the UNE-85238-91 standard for maximum safety.
Glazing
Glazing kit for quick installation
Consisting of a support wedge and rigid glazing wedges, this kit facilitates a quick and safe assembly of the system, reducing the movement of the glass and the residual deflection.
Compatible with 66.1 / 66.2 / 88.1 / 88.2 / 88.4 / 1010.1 / 1010.2 / 1010.4 glass.
Fixing to floor structure
Unified anchors for all balustrade solutions
This series of railings has unified all the necessary anchors for any of its solutions, making the assembly and installation process much easier and reducing the materials required for installation and manufacture.
Drainage
Internal drainage
Drainage hole diameter: 8 mm
Distance between holes: 1000 mm
External drainage
The regularly distributed drainage support allows optimum drainage in installations on or in front of the slab.
Systems and accessories
Leveling support
To adjust the profile in relation to the installation area up to 6.5 mm
Cover between glass
Provides an aesthetic and clean finish, preventing water entry.
Anti-slip device
Keeps the glass stable in sloping installations, such as on stairs.
Joiner pins
Ensure perfect alignment when installing the profiles.
LED lightning
The glazing wedge can easily accommodate LED strips to create lighting effects.
Finishing profiles
EPDM gaskets
The special design ensures that the rubber does not sink in, and offers a perfect fit with removable pieces.
Gasket support
The aluminium profiles and specific seals reduce the visible rubber section, making the system even more elegant.
Finishing profiles
The aluminium trims simplify installation and guarantee a flawless finish.
Facade finishing profiles
Top trim profiles for the installation of facades with thicknesses from 3 mm to 18 mm. Can be used with the same joint options as other trim profiles.
Handrails
A range of handrail options to create a railing to suit the aesthetics of your project: minimalist, round and rectangular, with or without LED lighting.
